Chun Zu CNH6L 2023

Machine Name: Chun Zu CPR Series Thread Rolling Machine

Thread diameter range: 2 – 42 mm

Thread length range: 3 – 250 mm

Shank length under head: 3 – 350 mm

Maximum rolling force: 150,000 kgf

Frame & slider material: Stress-relieved grey cast iron

Drive system: AC motor with inverter

Die pocket adjustment: 3-axis (X, Y, Z)

Die liner materials: Phosphoric bronze and hardened alloy steel
Frame design: Tie-bar construction

Customizable mechanisms: Yes – adaptable to product specifications
